Apex iScrub X70 Large L4 Autonomous Outdoor Scrubber with LiDAR + Depth-Camera Navigation
A large autonomous outdoor scrubber that maps and cleans wide open ground on its own — built for managers of factory roads, logistics yards and campuses.
L4 AutonomousLiDAR + Depth Cam±3 cm Accuracy5–6 h Runtime
The Apex iScrub X70 is a large L4 autonomous outdoor scrubber built for property and facility managers responsible for wide, hard open ground — factory roads, logistics yards, university campuses and large municipal grounds. It navigates with a LiDAR (0.15–120 m range) plus a depth camera and gyroscope, achieving ±3 cm positioning accuracy through multi-sensor fusion, so it cleans consistently even in dim light, among columns and on slopes. The 480 kg body climbs 8–10% grades and crosses ≤3 cm obstacles, runs 5–6 h per charge, and auto-generates cleaning reports over WIFI for accountability. One X70 keeps expansive grounds presentable around the clock with no operator. Backed by Changzhou Yongle — 20 years in industrial cleaning, 3,500+ enterprise clients.
Core Advantages
1. LiDAR + Depth Camera — ±3 cm Accuracy
A 0.15–120 m LiDAR, depth camera and gyroscope fuse for ±3 cm positioning. The X70 keeps its line in dim light, among columns and on slopes — far more reliable than single-sensor robots.
2. Large Body, Real Outdoor Capability
The 480 kg frame climbs 8–10% grades and crosses obstacles up to 3 cm with anti-fall protection above 5 cm, so it handles real factory roads and yards, not just smooth floors.
3. Long 5–6 h Runtime, Auto Report
A lead-acid pack runs 5–6 h per charge (6–7 h to refill) and the cloud auto-generates cleaning reports, giving managers proof of coverage across large sites.
4. L4 Autonomous — No Operator
Set the task and the X70 plans routes, avoids obstacles and returns to charge on its own. WIFI connectivity supports remote fleet monitoring and dispatch.
Technical Specifications
| Parameter | iScrub X70 |
|---|---|
| Model | iScrub X70 |
| Brand | Apex (by Changzhou Yongle Environmental Engineering Co., Ltd.) |
| Product Type | Large autonomous outdoor scrubber (multi-sensor) |
| Autonomy Level | L4 (unmanned, no operator follow-up) |
| Dimensions (L×W×H) | 1950 × 940 × 1440 mm |
| Weight | 480 kg |
| Environment | 0–45 °C / 20–70% RH |
| Depth Camera | Distance sensing, depth + obstacle avoidance |
| LiDAR | 1 unit, 0.15–120 m |
| Drive | Single steering motor |
| Gyroscope | Yes |
| Moving Speed | 0.3–1.0 m/s |
| Positioning Accuracy | ±3 cm (multi-sensor fusion) |
| Max Gradeability | 8–10% |
| Obstacle Crossing | ≤ 3 cm |
| Anti-fall | ≥ 5 cm |
| Battery | Lead-acid |
| Runtime | 5–6 h |
| Charge Time | 6–7 h |
| Charger | Communication-enabled |
| Network | WIFI |
Application Scenarios
Factory Roads & Parking Lots
The 480 kg body and 8–10% gradeability handle plant roads and lots; ±3 cm positioning keeps lines clean along curbs and around fixed assets.
Logistics Yards & Truck Lanes
Wide, dynamic yards demand constant tidiness. The X70 auto-reports coverage so managers verify clean lanes without walking the site.
University Campuses & Scenic Grounds
Large open areas with columns, slopes and varying light are exactly where LiDAR + depth-camera fusion outperforms simpler robots.
Municipal & Public Grounds
One supervisor runs the X70 over WIFI; auto-reports satisfy accountability needs for public-space maintenance.
Customer Pain Points & Apex Solutions
Pain 1 — Robots lose their way in dim or complex outdoor sites.
Solution: LiDAR + depth camera + gyroscope fusion holds ±3 cm accuracy even in low light, among columns and on slopes.
Pain 2 — Light robots can't handle real outdoor grades.
Solution: The 480 kg X70 climbs 8–10% grades and crosses ≤3 cm obstacles with anti-fall protection above 5 cm.
Pain 3 — No proof the grounds were actually cleaned.
Solution: The X70 auto-generates cleaning reports over WIFI, giving managers verifiable coverage.
Pain 4 — Outdoor sweeping is hard to staff.
Solution: L4 autonomy runs the X70 unattended; one supervisor monitors it remotely via WIFI.
Frequently Asked Questions
How accurate is the iScrub X70 navigation?
It fuses LiDAR (0.15–120 m), a depth camera and a gyroscope for ±3 cm positioning accuracy through multi-sensor fusion — reliable in dim light, among columns and on slopes.
What outdoor conditions can it handle?
The 480 kg body climbs 8–10% grades, crosses obstacles up to 3 cm, and has anti-fall protection above 5 cm. Operating environment is 0–45 °C at 20–70% RH.
How long does it run per charge?
A lead-acid battery delivers 5–6 h of runtime; a full recharge takes 6–7 h using a communication-enabled charger.
Does it report what it cleaned?
Yes. The X70 auto-generates cleaning reports over WIFI, so managers get verifiable coverage across large sites.
Is it autonomous — does it need an operator?
Yes, it is L4 autonomous: it plans routes, avoids obstacles and returns to charge on its own. WIFI supports remote monitoring and fleet dispatch.
What areas is the X70 best for?
Large outdoor hard ground — factory roads, logistics yards, campuses, scenic grounds and municipal areas. For compact indoor use see the iScrub X10 / X30.
What after-sales support do I get?
1-year warranty on core components, 7×24 remote diagnosis via the cloud platform, on-site commissioning by Yongle engineers, and an optional 3-year full-service agreement.
